Data Center Cooling
316L Precision Piping for AI Data Center Liquid Cooling — NVIDIA NVL Compliant
Industry Overview
The global AI data center liquid cooling market is experiencing explosive growth, driven by NVIDIA's GB200 NVL72 architecture requiring 120-140 kW per rack — far beyond the 15-20 kW capacity of traditional air cooling. NVIDIA explicitly mandates 316L stainless steel as the required material for CDU (Coolant Distribution Unit) core loops, replacing copper tubing and rubber hoses. The liquid cooling market is projected to grow from $48-67 billion in 2025 to $110-190 billion by 2030 at 18-25% CAGR. TOKO TECH supplies 316L electropolished seamless tubes, 304L/316L welded pipes, and stainless steel flanges meeting ASTM A269/A270 and NVIDIA NVL specifications for hyperscale AI data centers globally.
Key Challenges
NVIDIA NVL Material Compliance
NVIDIA GB200 NVL72 and Vera Rubin platforms mandate 316L electropolished seamless tube with Ra ≤ 0.4 μm for CDU core loops. Any deviation from this specification voids the cooling system warranty and risks GPU thermal throttling at scale.
Chloride-Induced Pitting in Hot Climates
Middle East data centers face cooling makeup water with 500-800 ppm Cl⁻, concentrating to 2,000-4,000 ppm after 3-5 cycles. 304 (PREN ~19) fails rapidly; 316L (PREN ≥ 26) maintains CPT above 40°C in these conditions.
Ultra-Cleanliness for Micro-Channel Cold Plates
Cold plate internal micro-channels are only 0.3-1.0 mm wide. Any particulate above 150 μm, corrosion byproducts, or residual manufacturing debris will cause channel blockage, flow imbalance, and GPU hotspot formation.
Massive Scale & Fast Delivery
A single 100 MW AI data center requires 20-35 tons of stainless steel pipe and fittings. Hyperscale deployments with 14-month build schedules demand JIT delivery across multiple construction zones with full material traceability.
TOKO TECH Solutions
316L Electropolished Precision Seamless Tube
Multi-pass cold-rolled 316L seamless tubes in φ9.5-φ25.4mm × 0.5-3.0mm, with bright annealed finish providing the ideal substrate for electropolishing to Ra ≤ 0.4 μm. ASTM A269/A270 S2 compliant with 100% bore inspection and helium leak testing ≤ 10⁻⁹ Pa·m³/s.
304L/316L Welded Distribution Piping
ASTM A358/A778 welded 304L pipes for facility water loops (DN150-DN400) and 316L seamless pipes for CDU-to-rack supply lines (DN25-DN80). Optimized cost-performance with 316L reserved for high-chloride CDU core circuits and 304L for secondary distribution.
Full Stainless Steel Flange & Fitting Package
Butt weld flanges (ASME B16.5, 150#-300# RF) in F304L/F316L, butt weld fittings (ASME B16.9 elbows, tees, reducers), and quick-disconnect adapter tubes in φ9.5/φ12.7/φ19.05mm — providing a single-source material package eliminating multi-vendor compatibility risks.
CDU OEM Supply Partnership
Direct supply to CDU manufacturers (Vertiv, Boyd, CoolIT) with annual framework agreements, consistent lot-to-lot quality with full heat-number traceability, and JIT delivery aligned to CDU production schedules.
Recommended Materials Data Center Cooling
View detailed chemical composition, mechanical properties, and corrosion resistance data for each recommended grade:
Need Piping Solutions for Data Center Cooling?
Tell us about your project requirements and we will recommend the optimal material and product specification.
Request Quote
